Oregon site data for civil engineers and surveyors

Know the ground before the site visit.

Click a tax lot for its zoning, slope, soils, public utilities and survey grid. Export lidar contours to AutoCAD or Civil 3D. Draw the site with a building pad, cut and fill and setbacks, and hand it off as a layered DXF and a PDF sheet.

Start a free 14-day trial See the deliverables

$99 a month for all of Oregon, plus $49 for each extra seat. No card needed for the trial.

Illustration: the layers a site plan DXF carries, drawn at 1" = 20'.

ParcelsAll 36 countiesAssessor tax-lot outlines

Elevation3-ft lidarDOGAMI, with USGS 3DEP behind it

Contours0.5 to 40 ftDXF, KML or KMZ

CoordinatesState PlaneOregon North or South, international feet

Map20+ layersEach with its own opacity

SheetC-0ZoneNotice · Oregon

Sequence of work

From an address to a drawing, in one browser tab

01
Find the lot

Type an address or click the map. The county's tax-lot outline, the assessor details and the zoning come up on one card.
02
Read the ground

Slope across the whole parcel in five bands, hillside checks, soils, and the nearest public mains and power lines.
03
Draw the site

Open the lot as a site plan. Place the building and paving, set a pad elevation, and see cut and fill, the daylight line and a section.
04
Take the files

A layered DXF in State Plane, a two-sheet PDF of the plan, contours as DXF, KML or KMZ, or the parcel report.

Parcel: Outline, tax lot, assessor details, land use, the state zoning class and the city's own zone code where it publishes one, and the elevation and slope at the point. Outlines in all 36 counties; in Union County only within the Upper Grande Ronde basin.
Soils: NRCS drainage class, hydrologic group, water table and septic rating. The septic rating is withheld when it would describe only a minority of the ground.
Utilities: The nearest public sewer, storm and water main, from nine Oregon utilities. Approximate, not a locate: call 811 and verify with the utility.
Power: High-voltage lines within 200 ft, with owner and voltage. Approximate alignment: verify against title and survey.
Survey: Township, range and section, and any Donation Land Claim, from BLM. Reference only, not a survey.
Highway: A state highway within 300 ft, with its milepoints and distance from the centerline, and ODOT's right-of-way maps for that stretch. ODOT publishes no right-of-way width, so none is shown.
Water: OWRD water rights, wells and groundwater restricted areas near the lot.

The slope section of a parcel card showing the share and acreage of the parcel in each of five slope bands, two hillside cautions for ground steeper than 25 and 40 percent, and the lidar slope layer shaded across the map. — DETAIL 2 · SLOPE ACROSS PARCELSCALE: NTS

The contour export panel for a selected parcel showing the lidar source, the coordinate system, a 2-foot contour interval, the fall across the area and its slope bands, with the contour layer drawn on the map. — DETAIL 3 · CONTOUR EXPORTSCALE: NTS

Map layersOver twenty on the map, each with its own opacity: zoning, flood, wetlands, streams, landslides, slope, hillshade, contours, soils, tax lots, the survey grid, water rights and wells, state highways, power lines and utility mains.

Site plan

A workspace for one lot, saved as you go

Open any lot from the map or from an address and it becomes a full-screen drawing of that lot, with the lidar, the mains and the lines around it already in place.

Draw on the lot

Rectangles, outlines and a pencil. Buildings, paving and areas, plus paths, swales, grade breaks and fences as lines, each on its own CAD layer.

Pad and earthwork

Set a pad elevation and see cut and fill in cubic yards, the balanced pad, the daylight line and a section profile, estimated from lidar ground.

Setbacks

Front, side and rear setbacks and maximum coverage, with the buildable envelope and its checks. Setbacks as you enter them, not the city's code.

Several lots, one site

Adjoining tax lots merge into one site with the old lot lines kept dashed. Lots across a street or alley stay separate pieces.

What's already there

Contours, utility mains, power lines, the survey grid, wells and state highways drawn around the lot, and carried into the files where their sources allow.

Your team

Share a plan with everyone on the team or with chosen people, to view or to edit.

Schedule of deliverables

What you hand to the drafter, the client or the file

MARK	DELIVERABLE	FORMAT	CONTENTS	NOTES
D1	Contours	DXF · KML · KMZ	Lidar contours for the parcel or a drawn box at 0.5 to 40 ft, with index and intermediate contours and their labels on their own layers.	Oregon State Plane North or South, international feet.
D2	Parcel report	PDF · 2 sheets	The tax lot over lidar contours with a State Plane title block, then every site check with one state and its source, and the filings on the tax lot.	Not checked is never a green mark. Nothing found means only that the source reported nothing.
D3	Site plan drawing	DXF	Each shape on its own layer, with the lot, the pad, the daylight line, the setback envelope and the contours, plus mains, power lines, the survey grid, highways and wells on theirs.	Utility layers only where the utility's terms allow a download.
D4	Site plan sheets	PDF · 2 sheets	The plan at 1" = 20', 1" = 40' or fit, with the map layers you turned on, then the site checklist for each lot.	Cut and fill estimated from lidar ground. Setbacks as entered.

What's in the DXF

AutoCAD R12 ASCII in Oregon State Plane North or South, international feet. Every source sits on its own named layer, so you freeze what you do not need, and a layer is written only when it has something on it.

LAYER	WHAT IT HOLDS	FROM
THE GROUND AND THE LOT
BOUNDARY	The extent of the export	The area you chose
PARCEL	The tax-lot outline, labelled with its number	County assessor
CONTOUR-INDEX	Every fifth contour	DOGAMI lidar, USGS 3DEP
CONTOUR-INTER	The contours between, at the interval you chose	DOGAMI lidar, USGS 3DEP
CONTOUR-TEXT	Contour elevation labels	DOGAMI lidar, USGS 3DEP
FROM A SITE PLAN
BLDG · PAVE · SITE-AREA	Buildings, paving and other areas you drew, or a layer name of your own	You
SKETCH-*	Paths, swales, grade breaks and fences or walls, each on its own layer	You
GRADE-PAD	The building pad at the elevation you set	You
GRADE-DAYLIGHT	Where the pad meets existing ground	Estimated from lidar ground
SETBACK	The buildable envelope from your setbacks	Setbacks as entered, not the city's code
LOTLINE-OLD	Old lot lines inside adjoining lots merged into one site	County assessor
WHAT'S AROUND IT
UTIL-SEWER · STORM · WATER	Public mains, approximate and not a locate	The publishing utility, only where its terms allow a download: today Grants Pass, and Eugene's storm lines
TRANSMISSION	High-voltage lines with owner and voltage, approximate alignment	HIFLD
PLSS-TWP · SEC · DLC	Township, section and Donation Land Claim lines, labelled on PLSS-TEXT; reference only, not a survey	BLM CadNSDI
ODOT-HWY	State highway centerlines; no right-of-way width	ODOT
WATER-POD	Water-right points of diversion	OWRD
WELLS	Wells	OWRD
NOTES	The coordinate system, the lidar source, and every data source with its limits	ZoneNotice

C-4 · Adjacent activity

What's been filed next door

The subdivisions, annexations, site plans and building permits filed near your sites come with the same plan, with hearing dates: 79,000+ filings, building permits from 28 cities and counties and land-use filings statewide. Put an alert on a city, a county or one lot and hear when something is filed.

General notes

Read before use

All data is screening data from public sources. It does not replace a field survey, a title report or a geotechnical report.
Utility mains are approximate and are not a locate. Call 811 and verify with the utility. They appear in downloads only where the utility's terms allow.
Parcel outlines come from county assessors and regional governments in all 36 counties. Union County's cover only the Upper Grande Ronde basin, and Grant County's date from 2016.
Slope and hillside checks never say buildable. A check whose source did not answer reads Not checked, never Clear.
Cut and fill are estimated from lidar ground: a screening figure, not a grading plan.
Setbacks are as you enter them, not the city's code.
Township, range, section and Donation Land Claims are BLM reference data, not a survey.
Highway distance is measured from the centerline. ODOT publishes no right-of-way width, so none is shown.
Power lines are an approximate alignment from HIFLD. Verify against title and survey.
Nothing found means only that the source reported nothing.

Parcel outlines Cities whose filings we collect

Key map · Coverage

All of Oregon, and only Oregon

Parcels: All 36 counties. Union County only within the Upper Grande Ronde basin; Grant County from a 2016 snapshot.
Lidar: Statewide, wherever DOGAMI or USGS 3DEP has flown
Utility mains: Albany, Corvallis, Eugene, Grants Pass, Hood River, Lebanon, Medford, Multnomah County and Clean Water Services
Filings: Building permits in 28 cities and counties; land-use filings from 171 cities and 33 of 36 counties

One plan, everything in it

14 days free · no card at signup

Standard

$99/ month

or $990 / year, 10 months for 12

+ $49 / month or $490 / year for each extra seat, up to 20

Start a free trial

Schedule of inclusions

Parcel outline, tax lot, zoning and assessor details, in all 36 counties
Soil, slope and elevation on the parcel card
Slope bands and hillside checks across the whole parcel
Public utility mains and power lines near the lot
Water rights, wells and groundwater restricted areas
Township and section, land claims and state highways
Lidar contours to DXF, KML or KMZ
Site plans with pad, cut and fill and setbacks, to DXF and PDF
The two-sheet parcel report PDF
Over 20 map layers, each with its own opacity
Every permit and land-use filing we cover, with alerts by email and text
Projects, saved maps and pinned sites
AI assistant
Team seats, with shared site plans and projects

$99 covers one user and all of Oregon. Once you subscribe, add seats for your team at $49 a month or $490 a year each, up to 20 — a seat added part-way through a billing period is charged for the days left, that day. After the free trial, the plan renews automatically — $99 every month, or $990 every year, plus any seats you have added — until you cancel. Cancel any time from your billing page; you keep access to the end of the period you have paid for. No refunds.

Good to know before you sign up

Questions

Does it cover my county?

Parcel outlines cover all 36 counties, from county assessors and regional governments. Union County's cover only the Upper Grande Ronde basin, and Grant County's date from 2016. Lidar, soils, flood, the survey grid and the other statewide layers work wherever their source has data.

Can I bring the contours into Civil 3D?

Yes. Contours download as a DXF in Oregon State Plane North or South, in international feet as Oregon law specifies, with index and intermediate contours on their own layers. Site plans download as a layered DXF too. Contours also come as KML or KMZ for Google Earth.

Is the utility data a locate?

No. It shows the public mains a utility publishes, approximately, so you know which utility to call. It is not a locate: call 811 and verify with the utility. Where no utility publishes its mains, the card says so rather than showing nothing.

Where does the data come from?

Public sources: county assessors, the cities' and utilities' own map services, and state and federal agencies such as DOGAMI, OWRD, ODOT, BLM and NRCS. Every check names its source, so you can check it yourself. It is screening data: it does not replace a field survey or a geotechnical report.

Can my team use it?

Yes. The $99 plan includes one person, and once you subscribe you can add seats from your Team page at $49 a month or $490 a year each — two people are $148 a month, three are $197, up to 20 seats. Everyone gets their own sign-in and the whole product, and site plans and projects can be shared to view or to edit. Need more than 20? Email support@zonenotice.com.

Is this an official record?

No. ZoneNotice is not affiliated with any city, county or state agency. It is a faster way to read what they already publish, and every record links back to its source.

Can I cancel?

Any time, from your own billing page — two clicks, no email and no phone call. The trial takes no card, so there is nothing to cancel if you decide it is not for you. Once you do subscribe the plan renews automatically at the same price until you cancel, and cancelling leaves you with access to the end of the period you have already paid for. There are no refunds.

Also built for contractors

Bidding the work rather than designing it? The same plan finds contractors and suppliers new permits and land-use filings in the areas they work.

ZoneNotice for contractors

Read your next site before you drive to it.
